Description
A pear-shaped screwgate for belay and rigging, machined from 7075 aerospace-grade aluminium. The wide radius keeps a munter hitch running smoothly and the 24.6 mm gate takes a gloved hand.
Technical specification
| Major axis (MBS) | 20 kN / 4,496 lbf |
|---|---|
| Minor axis | 15 kN / 3,372 lbf |
| Gate open | 7 kN / 1,574 lbf |
| Gate opening | 24.6 mm |
| Dimensions | 72 x 99.7 mm |
| Weight | 95.6 g / 3.4 oz |
| Material | 7075 aerospace-grade aluminium |
| Colours | Black, blue |
Standards & certification
- CE EN 12275
Part number K9961. Every unit is serial numbered and ships with its instructions for use and declaration of conformity. Bulk, private-label and OEM configurations available on request.
